• Specifications

    • Current Rating: 3A AC, DC
    • Voltage Rating: 250V AC Maximum
    • Operating Temp: -25°C ~ +85°C
    • Contact Resistance: 10mΩ Max
    • Insulation Resistance: 1000MΩ Min
    • Withstanding voltage: 1000V AC / minute
    • Terminal Material: Brass / Gold Flash
    • Material: Nylon 6T, UL94V-0
    • Solder Tab: Brass / Tin Plated
