• Specifications

    • Current Rating: 3A AC/ DC (Max)AWG#22
    • Voltage Rating: 250V AC/ DC
    • Temperature Range: -25°C ~ + 85°C
    • Contact Resistance: 20mΩ Max
    • Insulation Resistance: 1000MΩ Min
    • Withstanding Voltage:800V AC/Minute
    • Pin : Brass/ Tin-plated
    • Wafer Material: Nylon 6T,UL94V-0,natural
    • Solder tab:Brass/Tin-plated
