• Specifications

    • Voltage Rating: 50VAC DC.
    • Contact Rating: 1.0A AC DC (AWG 28).
    • Contact Resistance: Initial value/20 mΩ max; After environmental testing/40 mΩ max.
    • Insulator Resistance: 100 MΩ min.
    • Temperature Range: -25°C to +85°C.
    • Withstanding voltage: 500V AC/minute.

    Material and Finish

    • Insulator: Nylon 6T, UL94V-0
    • Insulator Color: Natural.
    • Contact: Phosphor Bronze, Gold-Plated.
    • Solder tad: Brass, Copper-undercoated, Tin-Plated.
