• Specifications

    • Current Rating: 0.5 AMP MAX
    • Dielectric Withstanding: 500V AC For One Minute
    • Contact Resistance: 30m OHMS MAX
    • Insulation Resistance: 100M OHMS Min At DC 500V
    • Operation Temperature: -20°C ~+85°C


    Materials

    • Housing: Hi-Temp. Plastic(UL 94V-0)
    • Shell: Copper Alloy Or Spcc, Nickel Plating
    • Terminal: Copper Alloy, Gold Plated On Contact Area Tin Plating On Solder Tail
