• Specifications

    • Current Rating: 7A AC, DC
    • Voltage Rating: 250V AC Maximum
    • Operating Temp: -25°C ~ +85°C
    • Contact Resistance: 10mΩ Max
    • Insulation Resistance: 1000MΩ Min
    • Dielectric Withstanding Voltage: 1500V AC,DC Min
    • Terminal Material: Brass / Tin-plated
    • Plating: Tin plated
    • Material: Nylon 66, UL94V-0
    • Color: White
