• Specifications


    Material

    • Insulator body(housing):PPS (black/UL94V-0).
    • Pin : Brass, machined.
    • Plating:Gold plated:2um/80u"nickel/full gold-flashed.


    Electrical:

    • Current rating: 3 Amps / contact max.
    • Operating: 60 Veff.
    • Insulation resistance: > 1000 MΩ at V=100V.


    Mechanical:

    • Operating temperature: Gold plated: -55℃ to +125℃.
    • Soldering temperature:+260℃,10s max.
