• Specifications

    • Current Rating: 1.5 amp max
    • Dielectric Withstanding: 500v ac for one minute
    • Contact Resistance: 30m ohms max
    • Insulation Resistance: 1000m ohms min at dc 500V
    • Operation Temperature: -30°C~+85°C


    • Housing: thermoplastics (ul 94v-0),blue (pantone 300c)
    • Shell: spcc, nickel plating
    • Terminal:  copper alloy, gold plated on contact area tin plating on solder tail
