• Specifications

    • 2 ~ 12 circuits available
    • Material: UL 94V-0 nylon 66
    • Accepts LT-MF300_M_ terminal
    • Mates with LH-MF300M-XX housing
    • Standard color: Black
    • Current rating(Wire size/Ampere): #20/5A #22/5A #24/4A #26/3A #28/2A #30/1A
    • Voltage rating: 250V AC(RMS) or DC
    • Contact resistance: 10mΩMax.
    • Dielectric strength: 1500V AC/minute
    • Temperature rise: 30°C max. (carry rated current load)
